Agent Identity Management System (AIMS)

Sources#

Summary#

AIMS is the conceptual model at the center of IETF Internet-Draft draft-klrc-aiagent-auth-03 (Kasselman/Lombardo/Rosomakho/Campbell/Steele/Parecki — Defakto/AWS/Zscaler/Ping/OpenAI/Okta; July 2026). Its thesis: an AI agent is a workload, and the identity, authentication, and authorization problems it raises are not new — they should be solved by composing existing, widely-deployed standards (WIMSE/SPIFFE workload identity, the OAuth 2.0 family, OpenID Shared Signals) rather than inventing agent-specific protocols. AIMS is "the set of functions required to establish, maintain, and evaluate the identity and permissions of an agent workload" — a conceptual model, not a product, protocol, or single architecture; it may live in one component or be spread across identity providers, provisioning services, authorization servers, policy engines, and runtime enforcement points.

Evidence caveat (attach everywhere): this is a standards-track proposal — an individual submission, Informational, with no IETF Working Group consensus yet (it profiles specs from the IETF, CNCF, and OpenID Foundation but is not itself ratified). Treat every MUST/SHOULD as the authors' recommendation, not an adopted standard. Its evidence: tier is practitioner-opinion.

Why it matters to this vault: the agent-security cluster was sourced almost entirely to one vendor ebook (Zero Trust for AI Agents). AIMS is the first standards-track, multi-vendor primary source on agent identity, and it directly targets two long-standing open questions — sub-agent credentialing (Agent Identity and Authentication) and the agent-to-agent trust protocol layer (Agent-Native Infrastructure).

Agents are workloads (the framing move)#

An Agent is a workload that iteratively interacts with an LLM and a set of Tools/Services/Resources until a terminating condition is reached (Figure 1 of the draft). Because it is a workload, it needs an identifier and credentials so it can be authenticated by the parties it touches — and, if it acts for a user or system, that principal must delegate authority to it, with the delegated context preserved into authorization decisions and audit trails. This reframing is what lets the whole problem be solved with workload-identity and delegated-authorization standards instead of new machinery.

Notably, "a Tool endpoint may itself be implemented by another AI agent" — so agent-to-agent is just the workload-to-workload case, and the same primitives cover it.

The layered stack (Figure 2)#

AIMS is a logical stack where higher layers depend on guarantees from lower ones, with two cross-cutting columns:

Policy | [ Monitoring, Observability & Remediation ] | Compliance
 | [ Authorization ] |
 | [ Authentication ] |
 | [ Provisioning ] |
 | [ Credentials ] |
 | [ Identifier ] |

Identifier → Credentials → Provisioning → Authentication → Authorization → Monitoring is the dependency chain.
Policy (§12) and Compliance (§13) span all layers but are declared out of scope — deployment-, regulatory-, and jurisdiction-specific, and explicitly not a standardization target. Policy MAY be any versioned, reviewable "policy-as-code" format.

Identifier: WIMSE, with SPIFFE as the deployed instance#

Each agent MUST have exactly one WIMSE identifier ([WIMSE-ID]) — a URI uniquely identifying a workload within a trust domain, stable for the identity's lifetime (authorization, delegation, and audit all key off it). It MAY be a SPIFFE ID (spiffe://<trust-domain>/<path>), which the draft calls the "widely deployed and operationally mature instance of the WIMSE identifier model." This is the concrete answer to "what is a per-agent identity" — a workload-identity URI, not an ad-hoc label.

Credentials + provisioning + posture assessment#

Credentials cryptographically bind the identifier to the agent. WIMSE defines the WIT (Workload Identity Token) and WIC (X.509 Workload Identity Certificate); SPIFFE defines X.509-SVID, WIT-SVID, and JWT-SVID. They SHOULD be short-lived with an explicit expiry. Static API keys are named an antipattern — bearer artifacts, not cryptographically bound, long-lived, hard to rotate.
Hardware-backed key storage (TPM, enclave, platform security module) is optional — "not required for interoperability." (This is the sharpest divergence from the ebook — see comparison below.)
Provisioning is runtime issuance/renewal/rotation in two phases (initial provisioning; automatic rotation before expiry). Short-lived credentials are offered as an alternative to explicit revocation: you don't revoke, you just don't renew.
Posture assessment happens at each provisioning/rotation event — the draft (v-02 onward) folded the old "attestation" section into provisioning and renamed it "posture management." It evaluates deployment-specific signals (hardware/TEE evidence, software-integrity measurements, supply-chain provenance, orchestration metadata, workload placement, operator assertions) to decide whether a credential issues, which identifier binds, what type, what attributes, and how long it lives. A single signal may suffice; higher-risk deployments require several. No particular attestation mechanism is required.
Credential exchange for legacy/proprietary environments incompatible with the primary credential: OAuth 2.0 Token Exchange, Transaction Tokens, or Workload Identity Federation mint a targeted secondary credential from the primary one.

The rule: LLMs never hold credentials#

"The Large Language Model MUST NOT have access to an agent's credentials or to credentials that may be needed to access tools and services." Rationale, stated verbatim: to prevent the LLM from using, exposing, or being manipulated via prompt injection into disclosing the credentials. This is the identity-layer sibling of the out-of-band reference-monitor doctrine — the secret sits outside the manipulable model, and the agent (the workload), not the model, wields it. (Added in -03 as [issue #127].)

Authentication: transport vs application layer#

Per the WIMSE architecture, auth can happen at either layer, and many deployments use both:

Transport-layer — mTLS, both endpoints presenting X.509 credentials; paired with short-lived SPIFFE/WIMSE identity it gives strong channel binding. Well-suited to service meshes (Istio, LinkerD). Limitation: intermediaries (proxies, API gateways, service meshes, load balancers, protocol translators) terminate and re-establish TLS, breaking end-to-end transport identity — and serverless/multi-tenant-edge/cross-domain topologies obscure transport identity.
Application-layer — survives intermediaries by binding identity above the transport. Two WIMSE mechanisms:
WIMSE Proof Tokens (WPTs) — a signed JWT proving possession of the WIT's private key, bound to a specific message context (e.g. an HTTP request), with claims aud/exp/jti/wth (hash of the WIT). Proof-of-possession, not bearer. Protocol-agnostic core (can bind Kafka, gRPC, non-HTTP).
HTTP Message Signatures ([WIMSE-HTTPSIG] over RFC 9421) — combine the WIT with a signature over request components (method, request-target, content digest, the WIT itself), giving proof-of-possession + message integrity end-to-end.
Limitation: no inherent channel binding, so implementations must defend against relay/replay via short lifetimes, audience restriction, nonces, and request binding.

Authorization: OAuth 2.0 as the delegation spine#

Agent Mission (§10.1) — an agent receives a Mission (a natural-language task) from a user, system, or another agent; translating the mission into concrete resource/authorization requirements is a planning step, out of scope (the draft cites Karl McGuinness's "Mission Shaping Problem"). This is where the wiki's agent-native "figure out the details" handshake meets a concrete auth model.
OAuth as delegation — the agent acts as an OAuth client; access tokens carry the agent identity as client_id and the delegated principal as sub. Flows: Authorization Code Grant when a user delegates (with phishing-resistant user auth like passkeys, and the agent authenticating to the AS with its Section-7 credentials, never static client secrets); Client Credentials / JWT Authorization Grant when the agent acts on its own behalf; and agents themselves can be OAuth protected resources invoked by a system or another agent.
Transaction Tokens (§10.5) — the blast-radius control for internal call chains. A broad access token passed between microservices is a theft/replay/lateral-move risk (an attacker who finds it in a log or crash dump can invoke a different transaction). Instead, exchange it for a transaction token: a downscoped token bound to one specific transaction (enriched with caller context, transaction context, a unique ID) that cannot be reused for another transaction or with modified details. Short-lived. A transaction token MAY be exchanged (OAuth Token Exchange) for an access token to call the next service.
Cross-domain chaining (§10.6) — when resources sit behind different authorization servers, the agent uses OAuth Identity and Authorization Chaining Across Domains (or the Identity Assertion JWT Grant / Transaction Token Grant profiles): exchange the current token for a JWT authorization grant, present it to obtain an access token for the target domain. This is the delegation-chain mechanism for ephemeral spawned agents.
Human in the loop (§10.7) — for high-risk actions the AS SHOULD decline or step up via CIBA (out-of-band approval on the user's device). Crucially, local UI confirmation is not authorization — the draft aligns with MCP's user-solicitation pattern but insists the agent MUST NOT treat a local approval as sufficient; it must be bound to a verifiable AS-issued grant. (Noted gap: CIBA only models client-initiated flows and doesn't map cleanly to mid-execution confirmation — exactly the gap the OpenID AuthZEN AARP draft is designed to close by generalizing CIBA into a policy-level prerequisite/approval pattern; see below.)
Tool-to-service (§10.8) — tools use Token Exchange / cross-domain chaining to reach downstream resources. Anti-pattern: a tool forwarding the access token it received from the agent (invites theft + lateral attacks) — the same containment logic as transaction tokens.
Discovery (§10.10) — in dynamic/ephemeral deployments, OAuth Authorization Server Metadata, Protected Resource Metadata, and Client ID Metadata Documents let agents bind to the right issuer/audience/flow at runtime without static config.

The OpenID AuthZEN drafts (AARP + COAZ): standardizing the authorization slice#

Where the IETF draft-klrc-aiagent-auth stack above standardizes identity, credentials, and delegated authority, the OpenID Foundation's AuthZEN Working Group is standardizing the authorization decision itself — and on 2026-06-15 (timed to Identiverse) it approved two documents as official Working Group Drafts: AARP and COAZ. Both are proposed drafts, not ratified standards — practitioner-opinion, and where they touch the same ground as the vault's empirical per-call-authz systems (ScopeGate, aiAuthZ) they are weighted below the measured work. They build on the AuthZEN Authorization API 1.0 and its Subject-Action-Resource-Context (SARC) decision interface — the interoperable "can this action happen now?" endpoint those two research systems each implement ad hoc.

AARP (Access Request and Approval Profile). Answers a question allow/deny authorization APIs historically couldn't: what is required before policy can authorize an action? When policy can't yet decide — an approval, consent, delegated authority, attestation, or risk assessment must first be satisfied — AARP defines interoperable patterns for requesting, tracking, satisfying, and re-evaluating those prerequisites, so applications, authorization systems, governance platforms, and agents coordinate while policy remains the decision-maker, evaluated at enforcement. The worked example is exactly this vault's vendor-payment case: an agent attempting an over-threshold transfer gets not a bare deny but a "not yet — here is what is required" signal, records a handle to the pending request, hands off or resumes later, and proceeds only after a manager approves and policy is re-evaluated. AARP explicitly generalizes CIBA: "this is to authorization prerequisites what CIBA is to authentication approval" — the same standardized, asynchronous, out-of-band interaction, but generalized to policy and satisfiable by a person or an automated governance system, not confined to CIBA's client-initiated authentication-approval shape. This is the direct proposed answer to AIMS's own acknowledged mid-execution-HITL gap (§10.7 above; Open Questions below).
COAZ (AuthZEN Profile for MCP Tool Authorization). A profile standardizing the mapping of MCP tool invocations into the AuthZEN SARC structure via metadata, so different enforcement points — API or AI gateways, service meshes, downstream systems — know how to authorize a tool call against a compatible PDP. It lets an MCP tool expose the authorization checks required to call it, bringing a per-invocation authorization control to agentic workflows — the standards-track form of the action-layer defense the MCP Tool Poisoning and per-call-authz pages argue for. Industry review spans Axiomatics, Cerbos, Okta, SailPoint, Indykite, Keycard, and C1.

The clean division of labor: AIMS (IETF) says who the agent/workload is and how authority delegates; the AuthZEN Authorization API + COAZ say whether this concrete call is allowed; AARP says what must first be true before that decision can even be reached. Together they place the agent-auth problem across two standards bodies — concrete evidence the governance layer is plural and moving, not stalled (see the sharpened Open Questions).

Observability and remediation as a security control (§11)#

Monitoring is "a security control, not solely an operational feature." Participants MAY subscribe to the OpenID Shared Signals Framework (SSF) with CAEP or RISC to receive signals (session revoked, risk elevated, token replay suspected, subject disabled) and MUST remediate promptly — discard cached tokens, re-acquire with tighter constraints, reduce privileges, re-run policy — and MUST NOT keep using authorization invalidated by a revocation. Deployments MUST keep tamper-evident audit logs (authenticated agent ID, delegated subject, resource, action + decision, timestamp/correlation ID, posture/risk state, remediation events) and SHOULD correlate across agents/tools/LLMs to detect replay, confused-deputy, privilege escalation, and anomalous sequences. Stable verifiable identifiers everywhere are what make "which entity did what, using which authorization context, and why access changed" reconstructable end-to-end.

Comparison: AIMS vs the Anthropic Zero-Trust ebook#

Both target per-agent identity for agentic Zero Trust and converge on the core: static API keys are unacceptable, credentials must be short-lived and cryptographically bound, per-agent identity is the keystone, least privilege / minimal scopes, and observability-as-security-control with tamper-evident audit. But they diverge on primitives and authority:

Dimension	Zero Trust for AI Agents (Anthropic ebook, vendor)	AIMS (IETF draft, multi-vendor standards)
Identity primitive	Cryptographic IDs → X.509 certs → hardware-backed HSM/TPM identity + remote attestation (tiered target state)	WIMSE/SPIFFE URI as the identifier (X.509-SVID or JWT/WIT-SVID)
Hardware attestation	The Advanced-tier target for internet-reachable production	Optional; "not required for interoperability" — one posture signal among many
Attestation model	Remote hardware attestation	"Posture assessment" at each issuance/rotation; deployment-specific signals (folds attestation into provisioning)
Authentication	Short-lived OAuth tokens → mTLS → hardware-bound credentials	Same, plus application-layer (WPT, HTTP Message Signatures) for when transport identity breaks
Delegation / sub-agents	Sub-agents inherit "up to the same permissions as the parent" (left largely open)	OAuth Token Exchange + Transaction Tokens + cross-domain chaining — downscoped, transaction-bound, not raw inheritance
LLM & credentials	Not stated as a rule	Explicit MUST NOT — the LLM never holds credentials
Authority	Single vendor; Claude Code as reference implementation	Six vendors, standards-track — but an individual submission, no WG consensus

The productive tension: the ebook drives toward hardware attestation as the aspirational endpoint; AIMS argues you can get the security property from short-lived, posture-assessed, delegated credentials without requiring hardware attestation on every ephemeral workload — and adds the delegation-chain machinery (transaction tokens, identity chaining) the ebook lacks. Neither is a ratified standard: the ebook is vendor practitioner-opinion, AIMS is standards-draft practitioner-opinion.

Connections#

Agent Identity and Authentication — the primary sibling; AIMS is the second (standards-track, multi-vendor) source on the same keystone control, and supplies the concrete identifier/credential/delegation primitives the ebook left at the tier-label level
Zero Trust for AI Agents — the vault's other agent-security framework (hub); AIMS composes existing standards where the ebook prescribes a tiered maturity model — convergences and divergences tabled above
Least Agency — AIMS enforces least agency through OAuth minimal scopes, audience restriction, and transaction-token downscoping (a token bound to one transaction that can't be reused) — the standards-layer instantiation of "restrict what each tool can do"
Blast Radius (Agentic) — transaction tokens, the no-token-forwarding anti-pattern, and short-lived non-revoked credentials are all blast-radius containment for the internal microservice call chain (limiting token theft, replay, and lateral movement)
Agent-Native Infrastructure — AIMS is a candidate answer to that page's open protocol-layer question: the trust/identity/accountability primitives for agent-to-agent negotiation, drawn from IETF/CNCF/OpenID standards (though governance is unsettled)
Out-of-Band Prompt-Injection Defense — same doctrine at the identity layer: keep the secret and the authorization decision outside the manipulable LLM (LLMs-never-hold-credentials; the AS, not local UI, authorizes) — the credential/authorization twin of the deterministic reference monitor
Off-Host, Identity-Bound Authorization — the standards layer vs a concrete shipped system: AIMS standardizes workload identity (WIMSE/SPIFFE) and delegated authority (OAuth token-exchange, transaction tokens); aiAuthZ (Kodathala, arXiv 2607.05518) is a running gateway that authenticates the human user per message (per-message HMAC + nonce) and could consume AIMS-issued identities as the service/principal inputs to its role + argument policy — composable at different granularities (AIMS binds identity to a workload/session/token; aiAuthZ to each user message), and empirical where AIMS is design-only. A single-author preprint, so weighted below this multi-vendor standards work on questions of adoption
Capability Gating Is Not Authorization — ScopeGate is the empirical research counterpart to AuthZEN/COAZ's proposed-standard authorize-each-call: both put a deterministic allow/deny decision over a concrete (tool, args) call, but ScopeGate is a measured in-framework PDP/PEP while AuthZEN's Authorization API + COAZ standardize the SARC decision interface and the MCP→SARC mapping (a WG draft, weighted below the measured system). AARP adds the "not yet — here is the prerequisite" shape a pure allow/deny gate like ScopeGate lacks
MCP Tool Poisoning — COAZ standardizes putting an authorization decision at the MCP tool-invocation point, the standards-track form of the action-layer defense that page argues must sit downstream of (defeated) detection
Agentic Prompt Injection — the LLM-never-holds-credentials rule is explicitly a prompt-injection defense: a hijacked model can't disclose a secret it never had
MCP and Computer Use — AIMS aligns its human-in-the-loop model with MCP's user-solicitation pattern, and treats MCP tools as the resource surface OAuth authorizes; but insists local approval is not authorization
Hermes Agent — a shipped contrast: Hermes secures multi-user agent access with an ad-hoc DM-pairing + allowlist (human-auth) plus container-as-boundary, where AIMS proposes standards-based workload identity + delegated authorization; the gap between practice and the proposed standard
OpenAI — Nick Steele (OpenAI) is a co-author, alongside Defakto, AWS, Zscaler, Ping Identity, and Okta

Open Questions#

No WG consensus. This is an individual submission profiling other still-in-progress drafts (WIMSE identifier/creds/WPT/HTTP-sig, OAuth transaction-tokens, identity-chaining are all Internet-Drafts too). Which of these primitives actually reach RFC, and does the composition survive WG review? "Who governs the agent-auth protocol layer" (Agent-Native Infrastructure) is proposed (IETF/CNCF/OpenID) but not settled. Sharpened by the OpenID AuthZEN drafts: the authorization slice is being standardized in a different body from AIMS's IETF identity/delegation work — the OpenID Foundation's AuthZEN WG approved AARP + COAZ as Working Group Drafts (a step past AIMS's individual-submission status, though still pre-ratification, community-review drafts). So the governance layer is concretely plural (IETF for workload identity + delegated authority; OpenID for the authorization decision + prerequisites) and actively moving — not one arbiter but a cross-body division of labor whose eventual composition is itself unsettled. Sharpened again 2026-08-04 by a third venue that ships: MCP spec revision 2026-07-28 (MCP Specification Changelog — 2026-07-28, vendor-claim) legislates its own client-registration and code-redemption rules under neither body — issuer-keyed non-reusable client credentials as a MUST, RFC 9207 iss validation as a MUST, and RFC 7591 Dynamic Client Registration deprecated in favor of Client ID Metadata Documents, the same primitive §10.10 above already names under Discovery. Two things follow. The composition question gains its first concrete convergence — an independent protocol reached for CIMD without coordinating with this draft — and it also gains a fourth arbiter, one that is not a standards body deliberating but a de-facto protocol shipping requirements into implementations while IETF and OpenID are still at draft. The trigger event for this question was always ratification; the observation is that a de-facto layer may settle the primitives before ratification does. Still #oq/wait — the question is which primitives reach RFC and whether the composition survives WG review, and neither has happened.
Mission → authorization is out of scope. The hardest part — translating a natural-language mission into concrete scopes/resources safely — is explicitly deferred as a "planning step." A manipulated planning step requests over-broad authorization; AIMS gives it clean primitives but no account of securing the translation itself.
Mid-execution human-in-the-loop. The draft admits CIBA only models client-initiated approval and "doesn't map well" to confirmation needed mid-execution — an acknowledged specification gap. Addressed (in proposal) by the OpenID AuthZEN AARP draft: AARP generalizes CIBA's async out-of-band interaction into a general prerequisite/approval pattern — "not yet, here is what is required" — not confined to client-initiated flows and satisfiable by a person or an automated governance system mid-flow, with policy re-evaluated at enforcement. So the gap now has a proposed standards answer — but a Working Group Draft, not a ratified spec, and not yet integrated with AIMS's IETF stack.
Posture assessment is deployment-specific by design. By requiring no particular attestation mechanism, AIMS makes interoperability of trust assurance (not just protocol) unspecified: two conformant AIMS deployments can assess posture with wholly different, non-comparable signals.
No empirical evaluation. Unlike Out-of-Band Prompt-Injection Defense (which at least ran one adaptive reproduction), AIMS is a design document with no measured attack-resistance — its security rests on the composed specs' own (mostly non-agentic) threat models.

Sources#

AI Agent Authentication and Authorization — IETF Internet-Draft draft-klrc-aiagent-auth-03, AI Agent Authentication and Authorization (Informational, individual submission), 6 July 2026, practitioner-opinion. §4 (agents are workloads, Figure 1), §5 (AIMS stack, Figure 2), §6 (WIMSE/SPIFFE identifier), §7 (credentials; static-key antipattern; hardware-backing optional), §8 (provisioning + posture assessment; LLMs-never-hold-credentials rule), §9 (transport mTLS vs application-layer WPT / HTTP Message Signatures), §10 (OAuth delegation, mission, transaction tokens, cross-domain chaining, CIBA human-in-the-loop, tool-to-service, discovery), §11 (SSF/CAEP/RISC monitoring + tamper-evident audit)
MCP Specification Changelog — 2026-07-28 — Model Context Protocol project, Key Changes for spec revision 2026-07-28, vendor-claim. Minor changes 7–9 and Deprecated 4: RFC 9207 iss validation, credentials keyed to the issuing authorization server, DCR application_type, and RFC 7591 DCR deprecated in favor of Client ID Metadata Documents. Used only for the plural-governance question — the point is where these rules are being made, not their merits
OpenID Foundation advances authorization for the agent era with new AuthZEN Working Group Drafts — OpenID Foundation, OpenID Foundation advances authorization for the agent era with new AuthZEN Working Group Drafts, 15 June 2026, practitioner-opinion (a standards-body announcement of newly-approved Working Group Drafts — proposals, not ratified specs; framed as proposed throughout, and weighted below the vault's empirical per-call-authz papers where they overlap). Supplies: AARP (Access Request and Approval Profile — prerequisite/approval pattern generalizing CIBA beyond client-initiated flows), COAZ (AuthZEN Profile for MCP Tool Authorization — MCP invocations → Subject-Action-Resource-Context / Authorization API 1.0), the OIDC→OAuth→CIBA→Verifiable-Credentials→AARP progression, and the industry-participation list (Axiomatics, Cerbos, Okta, SailPoint, Indykite, Keycard, C1)
